Brand : UNOX

BAKERTOP MIND.MapsTM ONE Combi oven for Bakery and Patisserie

     Technologically advanced combi oven for fresh or frozen baking processes and for gastronomy cooking processes (dehydrating, steaming, low temperature baking, sous vide cooking, roasting, grilling, pan frying, regeneration and plated regeneration) thanks to the Unox Intensive Cooking and Intelligence Performance technologies which guarantee perfect results and repeatability for any load size. Automatic management of cooking processes (CHEFUNOX) for perfect results even without a trained staff.


Standard Technical Features

Manual cooking

  ● Temperature: 30 °C – 260 °C

  ● Up to 9 cooking steps

  ● CLIMA.Control: humidity or dry air set by 10%

  ● Delta T cooking with core probe


  ● 1000+ programs

  ● MIND.Maps™: draw the cooking processes directly on the display

Standard Technical Features

  ● ROTOR.Klean™: automatic washing system

  ● Cooking chamber in high-resistance AISI 304 stainless steel with rounded edges

  ● Double glass

  ● Cooking chamber lighting through LED lights embedded in the door

  ● Tray supports with anti-tipping system

  ● Drip collection system integrated in the door and functional even with the door open

  ● 4-speed fan system and high-performance circular resistance

  ● Integrated DET&Rinse™ detergent container

  ● Wi-Fi / USB data: download/upload HACCP data

  ● Wi-Fi / USB data: download/upload programs

Advance and Automatic Baking Features

Unox Intensive Cooking

  DRY.Maxi™: rapidly extracts the humidity from the cooking chamber

  STEAM.Maxi™: produces saturated steam

  AIR.Maxi™: manage fans auto-reverse and pulse function

  CLIMALUX™: total control of the humidity in the cooking chamber

Data Driven Cooking

  Control and monitor the operating conditions of your ovens in real-time, create and share new recipes. The AI transforms the consumption data into useful information in order to increase your daily profit. Create, understand, improve

Power supply


Type of control Digital
Number of trays

4 Tray (Size 600x400 mm.)


80 mm


50 / 60 Hz


230V 1N~ /400V 3N~


85 Kg

Electric power

7,4 kW


Width: 860 mm

Depth: 957 mm

Height: 675 mm
