XVL 1 Counter PSP

Brand : CARPIGIANI

Single flavor counter top pump or gravity machine to produce soft ice cream single portions and frozen yogurt

Small, cool look, and able to ensure high production results

High production performance
Little in size, big in production performance

Versatile
To produce both delicious single portions and take away cones giving free space to your imagination

Small
The smallest machine in that range and the most adaptable to any situation

Overview
Features & Benefits	Direct expansion cooling cylinder Optimizes refrigeration efficiency for fast freeze downtime, less waste of product ensuring higher quality and energy saving Rear panel chimney Allows to optimize space and to place machines next to each other Interactive display Communicates with the operator delivering instructions and data regarding machine performance Tank agitator Prevents product stratification and helps to reduce foam by maintaining a fluid consistency Self closing device The dispenser close automatically stopping the flow of ice cream, eliminating any waste and preventing mess Adjustable ice cream flow Adjustable product flow to meet your specific dispensing speed and volume requirements Independent pump transmission Helps to extend the pump and gears life and allow flexibility and maximum performance Self-pasteurization With our self-pasteurization system the machine can be cleaned and disassembled only 9 times per year Defrost system Possibility to heat the cylinder to simplify the cleaning procedure

Technical Characteristics
Flavour	1
Mix Delivery System	Pump or Gravity
Cylinder Capacity
Lt	1,75
Tank Capacity
Min. lt	13
Hourly production
75 gr portions	310 for the Pump model, 265 for the Gravity model (production capacity depends on the mix used and the room temperature).
Electrical
Cooling System	Air, water optional
Hz	50*
Ph	3*
Volt	400*
Fuse Size A	10
Rated Power Input kW	2,4
Refrigerant	R452 (alternative solutions available)
Dimensions
Net Weight kg	170 kg for the Pump model, 160 kg for the Gravity model.
Note	*other voltages and cycles available upon request. XVL 1 Counter PSP is produced by Carpigiani with Quality System UNI EN ISO 9001. All specifications mentioned must be considered approximate; Carpigiani reserves the right to modify, without notice, all parts deemed necessary.
