191 SA P SP

Brand : CARPIGIANI


Single flavour self-dispensing counter-top soft serve machine

The 191 machine is a semi-automatic Portion controller

High efficiency components
Achieve top performances and non-stop production

High performance machine
Its best location is in sites with many potential consumers, such as shopping centers, arcades, water parks, amusement parks, etc.

Overrun and consistency control
Different consistency control settings for various mix types and easy adjustable overrun



แบ่งปันให้เพื่อนของคุณ

Overview
Optional configurations

Self-pasteurization

With our self-pasteurization system the machine can be cleaned and disassembled 9 times per year

Teorema Remote Control

It gives very important info about the machine, it facilitates the service system and helps the cleaning schedule

Protected dispensing

After placing the cup on the cup holder and having selected the flavour, the gelato is dispensed, always in a protected area

Features & Benefits

Direct expansion cooling cylinder

Optimizes refrigeration efficiency for fast freeze downtime, less waste of product ensuring higher quality and energy saving

Rear chimney and reduced footprint

Space optimization and machine installation next to each other

Interactive display

Communicates with the user giving him instructions and data regarding the performance of the machine

Gear pump

It pressurizes the mix with air and feeds the production cylinder for a creamier gelato with a high volume increase

High capacity cylinder

Perfect for all dispensing circumstances, including the moments of greater production pressure

Product protection

The upper refrigerated tank lid is key locked to prevent product contamination

Simplified cleaning

Cleaning is facilitated thanks to the possibility of heating the cylinder and to the easy disassembly of the dispensing unit

Technical Characteristics
flavour

1

Mix Delivery System

Pump

Cylinder Capacity
Lt

1,75 lt

Tank Capacity
Lt

13 lt

Hourly production
75 gr portions

250 (production capacity depends on the mix used and the room temperature)

Electrical
Cooling System

Air (water optional)

Volt/Hz/Ph

400/50/3 (other voltages and cycles available upon request)

Fuse Size A

10 A

Rated Power Input kW

2,9 kW

Refrigerant
Refrigerant

R452 (alternative solutions available)

Dimensions
Net Weight kg

188 kg

Note

191 SA P SP is produced by Carpigiani with Quality System UNI EN ISO 9001. All specifications mentioned must be considered approximate; Carpigiani reserves the right to modify, without notice, all parts deemed necessary.

SPEC SHEET
