High-Efficiency Gas Fryers with Filtration

Brand : FRYMASTER

Regular filtration is the key to extending oil life and to ensuring quality fried foods. Frymaster has both built-in and portable filters that make this process quick, easy and convenient.

High-Efficiency Gas Fryers with Filtration

Designed for trouble-free filtering of fryer batteries without wasting valuable space

Frymaster’s H55 is a premium open-pot fryer that combines state-of-the-art technology with decades of frying experience and customer satisfaction to set the standard for high-efficiency frying. The ENERGY STAR^® rated H55 fryer saves thousands of dollars annually on energy costs. H55 fryers have long been the trusted choice of chains and independent operators worldwide because their efficient, state-of-the-art heat transfer system, precise controls and durability have stood the test of time.

Infrared burners and blower system delivers an ultra-refined air-gas mixture so the fryer operates well in any gas application such as at high altitudes, in environments where air circulation is sub-optimal or when the heating value of the gas is diminished.

Frymaster’s renowned, built-in filtration system puts filtration where it’s most convenient to use -- right within the fryer battery -- eliminating the need for additional floor and storage space.

The filtering process is fast and easy, encouraging frequent filtering -- a critical part of maximizing oil life, especially with trans-fat free oils. It is also sequential, so one fryer may be filtered while the others are still in use. It is engineered with features that allow added convenience, easier serviceability and allows for using three different filter mediums with one pan.

This system is enhanced with a gravity draining system that allows residual oil to drain into the filter pan so that drain lines are always open. The filter, housed beneath two Frymaster fryers or one fryer and a spreader, is capable of filtering up to six fryers, individually, without having to be moved from fryer to fryer, saving valuable labor. One fifty-pound fryer can be filtered in about four minutes, while other fryers in the battery keep on cooking.

Large sump with secure hold-down ring ensures proper vacuum and superior oil filtration. The stainless steel filter pan slides out easily over floor mats and uneven floor tiles.

แบ่งปันให้เพื่อนของคุณ

Baskets	Two twin per frypot
Boil-out	Boil-out temperature control
Built-in Filtration	- Space-saving filter fits inside fryer cabinet housing two full or qualifying split frypots in two left most cabinets of the battery - Filter pan designed on rails to clear floormats for easy cleaning - Sloped drain pan leaves minimal residue oil behind after filtering - Large 3" (8.0 cm) round drain line allows oil to drain freely - Filter cycle is complete from start to finish in less than 5 minutes while other frypots in the system are in use - Filters up to 6 fryers in one battery - 1/3 H.P. filter motor - 4 GPM (15 LPM) pump - Stainless steel crumb catcher - Filter starter kit
Burners	Infrared burners
Capacity	50-lb oil capacity
Casters
Cleaning	Ample cleaning space when filter pan is removed
Cold Zone	Deep cold zone with 1-1/4" full-port, ball-type drain valve
Construction	Stainless steel frypot, door and cabinet
Controllers	Digital
Design	Open-pot design (split or full), easy to clean
Drain	Large 3-inch round drain line creates 13% more capacity for oil to drain freely
Drain Safety Switch	Drain safety switch on all Frymaster filter system fryers
Filter Pan	Fits conveniently under two or more fryers or one fryer and spreader requiring no additional floor space.
Frying Area	14" x 15" x 4-1/2" (35.6 x 38.1 x 11.4 cm) per full frypot 6-1/2" x 15" x 4-3/4" (16.5 x 38.1 x 12.1 cm) per split frypot
Gas Connection	See spec sheet
Ignition	Electronic ignition
Input	80,000 Btu/hr (20,151 kcal/hr) (23.4 kw/hr) (84.4 MJ/hr) per full frypot; 40,000 Btu/hr input (10,075 kcal/hr) (11.7 kw/hr) (42.2 MJ/hr.) per split frypot
Labor Saving	Sloped drain pan leaves minimal shortening residue behind after filtering
Melt Cycle	Automatic
Rear Oil Flush
Temperature Probe	Center-mounted, RTD 1° compensating temperature probe

Technical Specifications
H55 High Efficiency Gas Fryer with Filtration FPH155	W x D x H 15-5/8" x 29-5/8" x 45-5/8" 39.7cm x 75.2cm x 115.9cm Weight 306 lb ( 138.8 kg ) Power Input Type Gas - Natural Certifications
H55 High Efficiency Gas Fryer with Filtration FPPH255	W x D x H 31-3/8" x 29-5/8" x 45-5/8" 79.7cm x 75.2cm x 115.9cm Weight 492 lb ( 223.2 kg ) Power Input Type Gas - Natural Certifications
H55 High Efficiency Gas Fryer with Filtration FPPH355	W x D x H 47" x 29-5/8" x 45-5/8" 119.4cm x 75.2cm x 115.9cm Weight 671 lb ( 304.4 kg ) Power Input Type Gas - Natural Certifications
H55 High Efficiency Gas Fryer with Filtration FPPH455	W x D x H 62-5/8" x 29-5/8" x 45-5/8" 159.1cm x 75.2cm x 115.9cm Weight 881 lb ( 399.6 kg ) Power Input Type Gas - Natural Certifications
H55 High Efficiency Gas Fryer with Filtration FPPH555	W x D x H 78-1/8" x 29-5/8" x 45-5/8" 198.4cm x 75.2cm x 115.9cm Weight 1076 lb ( 488.1 kg ) Power Input Type Gas - Natural Certifications
H55 High Efficiency Gas Fryer with Filtration FPPH655	W x D x H 93-3/4" x 29-5/8" x 45-5/8" 238.1cm x 75.2cm x 115.9cm Weight 1236 lb ( 560.6 kg ) Power Input Type Gas - Natural Certifications
Accessories
Basket Lifts (except Australia)	Automatic basket lifts
Baskets	Full and triplet (triplet only available on GF40)
Brush	Filter brush
Chicken/Fish Tray
Controllers	CM3.5 or SMART4U^® 3000
Cover	Filter cover
Dump Pan	Cafeteria-style dump pan
Dump Pan	Perforated scoop-type dump pan
External Oil Discharge	Available on built-in filter batteries of 2 or more frypots or a frypot/spreader -- must specify front or rear connection.
Foam Deck Basket Banger
Fryer's Friend	Clean-out rod
Frypot Covers
Lamp	Rod-style heat lamp
Lamp	Bulb-style heat lamp
Paper	Filter paper
Sediment Tray(s)
Spreader Cabinet	Must fit within a 6-cabinet fryer battery
