H55, H55-2
Brand : FRYMASTER
H55 and H55-2 High Efficiency
Gas Fryers
Frymaster’s H55 is a premium open-pot fryer that combines state-of-the-art technology with decades of frying experience and customer satisfaction to set the standard for high-efficiency frying.
Specifically designed
for high capacity, reliability, versatility and efficiency
Frymaster’s H55 is a premium open-pot fryer that combines state-of-the-art technology with decades of
frying experience and customer satisfaction to set the standard for high-efficiency frying. The ENERGY STAR® rated
H55 fryer saves thousands of dollars annually on energy costs. H55 fryers have long been the
trusted choice of chains and independent operators worldwide because their
efficient, state-of-the-art heat transfer system,
precise controls and durability have stood the test of time.
Infrared burners and blower system delivers an ultra-refined air-gas mixture so the fryer
operates well in any gas application such as at high altitudes, in environments
where air circulation is sub-optimal or when the heating
value of the gas is diminished.
The split-pot model has all of the
features and options of the full-pot H55 and gives the operator
the discretion of using only half the fryer.
The optional stand-alone
spreader cabinet can include a holding station with heat lamp option. The holding stations are
available with cafeteria-style pan or scoop-type pan.
*Liter conversions are
for liquid shortening @70°F.
แบ่งปันให้เพื่อนของคุณ
| Baskets |
Two twin |
| Boil-out |
Boil-out temperature control |
| Burners |
Infrared burners: 80,000 Btu/Hr. (20,151 kcal) (23.4 kw) input |
| Capacity |
50-lb oil capacity |
| Cold Zone |
Deep cold zone with 1-1/4" IPS ball-type drain valve |
| Construction |
Stainless steel frypot, front, door, and backsplash/flue
cover with aluminized sides |
| Controller |
CM3.5 |
| Design |
Open-pot design (split
or full), easy to clean |
| Drain Safety Switch |
Drain safety switch on all Frymaster filter system fryers |
| Frying area |
14" x 15" x
4-1/2"
(35.6 x 38.1 x 11.4 cm) per
full frypot |
| Gas Connection |
3/4" (1.91cm) (NPT) gas
connection |
| Ignition |
Electronic ignition |
| Input |
80,000 Btu/hr. (20,151 kcal) (23.4
kw) |
| Legs |
8-1/2" (22
cm) adjustable
legs |
| Melt Cycle |
Automatic |
| Temperature Probe |
Center-mounted, RTD 1° compensating temperature
probe |
| Technical Specifications |
H55 and H55-2 High Efficiency Gas
Fryers |
| W x D x H |
15-5/8"
x
29-5/8" x 45-5/8"
39.7cm x 75.2cm x 115.9cm |
| Weight |
202.8 lb ( 92 kg ) |
| Power Output |
80000.00 N/A |
| Power Input Type |
Gas - Natural |
| Certifications |
|
| Accessories | |
| Basket Lifts (except Australia) |
Automatic basket lifts (units with basket lifts
require casters to be purchased also) |
| Baskets |
Full and triplet (triplet
only available on GF40) |
| Casters |
Set of four |
| Chicken/Fish Tray | |
| Controllers |
Digital Controller, SMART4U® 3000 |
| Cover |
Stainless steel frypot cover |
| Foam Deck Basket Banger | |
| Sediment Tray | |
| Spreader Cabinet |
Stand-alone
spreader cabinet |
