XVL 1 Classic
Brand : CARPIGIANISingle flavour floor standing machine to produce soft ice cream and
frozen yogurt
Maximum versatility and high production capacity: pump or gravity fed, the machine suitable
for all customers
Large production capacity
Continuous production is guaranteed even during peak hours
Production flexibility and versatility
Satisfy all your customers’ needs
by offering a wide range of products: soft
serve ice cream, frozen yogurt, fruit sorbets and single portions
Overrun and consistency control
Different consistency control settings for various mix types and easy
adjustable overrun
แบ่งปันให้เพื่อนของคุณ


Overview | |
Optional configurations |
Self-pasteurization With our self-pasteurization system the machine can be cleaned and
disassembled only 9 times per year Teorema Remote Control It gives very important info about the machine, it
facilitates the service system and helps the cleaning schedule Single portions kit Optional nozzles to fill cups and tartlets and to produce
ice cream single portions Mixer Optional mixer with disposable spoons to swirl toppings into
the ice cream Dry Filling System
Possibility of preparing the mix directly in the hopper by
adding water and dry mix |
Features & Benefits |
Stainless steel pressurized gear pump in Advanced
Thermoplastic Polymer (P model) The pump ensures the best ice cream texture, quality and
high overrun, adjustable from 40% to
80% Independent pump transmission (P model) Helps to extend the life-span of the pump and gears and allows for flexibility and
maximum performance Gravity fed system (G model) Control valves naturally add air to the mix producing a firm
and dry ice cream having an overrun up to 40% Tank agitator Prevents product stratification and helps to reduce foam by
maintaining a fluid consistency High efficiency beater in POM Single piece for a dry, compact gelato Self closing device The dispenser closes automatically stopping the flow of ice
cream, eliminating any waste and preventing mess Adjustable ice cream flow Adjustable product flow to meet your specific dispensing
speed and volume requirements Direct expansion cooling cylinder Optimizes refrigeration efficiency for fast freeze downtime,
less waste of product ensuring higher quality and energy saving Defrost system
Possibility to heat the cylinder to simplify the cleaning
procedure |
Technical Characteristics | |
flavour |
1 |
Mix Delivery System |
Pump
or Gravity |
Cylinder Capacity | |
lt |
1,75 |
Tank Capacity | |
lt |
13 |
Hourly production | |
75 gr portions |
465 for Pump model; 440 for Gravity model. (production
capacity depends on the mix used and the room temperature) |
Electrical | |
Hz |
50* |
Ph |
3* |
Volt |
400* |
Fuse Size A |
10 |
Rated Power Input kW |
2,5 kW
for the Pump version, 2,4 for the Gravity version. |
Refrigerant | |
Refrigerant |
R452 (alternative
solutions available) |
Dimensions | |
Net Weight kg |
230 kg
for the Pump model, 225 kg for the Gravity model. |
Air-cooled version | W x D x H cm |
45 x 93 x 160,5 |
Note |
Note *other
voltages and cycles available upon request. XVL 1 Classic is produced by
Carpigiani with Quality System UNI EN ISO 9001. All specifications mentioned must be
considered approximate; Carpigiani reserves the right to modify, without
notice, all parts deemed necessary. |
SPEC SHEET |
