XVL 3 Steel

Brand : CARPIGIANI


Twin twist floor standing pump machine to produce soft ice cream and frozen yogurt

Very high production capacity and versatility: the machine satisfies all customers needs

Large production capacity
Continuous production is guaranteed even during peak hours

Production flexibility and versatility
Satisfy all your customers needs by offering a wide range of products: soft serve ice cream, frozen yogurt, fruit sorbets and single portions

Overrun and consistency control
Different consistency control settings for various mix types and easy adjustable overrun


แบ่งปันให้เพื่อนของคุณ

Overview
Optional configurations

Self-pasteurization

With our self-pasteurization system the machine can be cleaned and disassembled only 9 times per year

Teorema Remote Control

It gives very important info about the machine, it facilitates the service

Single portions kit

Optional nozzles to fill cups and tartlets and to produce ice cream single portions

Mixer

Optional mixer with disposable spoons to swirl toppings into the ice cream

Dry Filling System

Possibility of preparing the mix directly in the hopper by adding water and dry mix

Features & Benefits

Two beater motors and separate cooling systems

The independent cylinders allow simultaneous production of different types of ice cream

Stainless steel pressurized gear pump in Advanced Thermoplastic Polymer

The pump ensures the best ice cream texture, quality and high overrun, adjustable from 40% to 80%

Independent pump transmissions

Help to extend the pump and gears life and allow flexibility and maximum performance

Interactive display

Communicates with the operator delivering instructions and data regarding machine performance

Tank agitators

Prevent product stratification and help to reduce foam by maintaining a fluid consistency

2E-RSI high efficiency beater

Interchangeable plastic scrapers and shaft for a soft, creamy gelato

Self closing device

The dispensers close automatically stopping the flow of ice cream, eliminating any waste and preventing mess

Adjustable ice cream flow

Adjustable product flow to meet your specific dispensing speed and volume requirements

Direct expansion cooling cylinders

Optimize refrigeration efficiency for fast freeze downtime, less waste of product ensuring higher quality and energy saving

Defrost system

Possibility to heat the cylinders to simplify the cleaning procedure

Technical Characteristics
Flavour

2+1

Mix Delivery System

Pump

Cylinder Capacity
Lt

1,75

Tank Capacity
Lt

13+13

Hourly production




75 gr portions

695 (production capacity depends on the mix used and the room temperature)

Electrical
Cooling System

Air, water optional

Hz

50*

Ph

3*

Volt

400*

Fuse Size A

16

Rated Power Input kW

5,0

Refrigerant

R452 (alternative solutions available)

Dimensions
Net Weight kg

310

Air-cooled version | W x D x H cm

50 x 93 x 160,5

SPEC SHEET
